China Flatbed Semi-Trailer – 20-40 FT Length Adjustment for Different Containers & Cargo Types Suppliers, SKD
Product Description
📋 Product Specifications
| Name | 40 FT Flatbed semi trailer |
| Dimension | 12500*2500*1550mm |
| Payload | 40ton, 60ton, 80ton |
| Tire | 11R22.5, 12R22.5, 315/80R22.5, Triangle, Double coin, Linglong. |
| Axles | 13T/16T/20T Fuwa, BPW |
| King Pin | 2 inch or 3.5 inch JOST Brand |
| Brake System | KEMI, WABCO with Four double Two single air chamber |
| Landing Gears | Standard 28 Ton, Fuwa, JOST |
| Suspension | Mechanical suspension, Air suspension |
| Floor | 3mm, 4mm, 5mm diamond steel plate |
| Twist locks | 4 / 8 / 12 sets |
| Functions | Transport container, loose cargo, bulk cargo, etc |
🚀 Key Advantages
High strength steel material is used to manufacture the flatbed, ensuring a higher loading capacity and a longer service life.
Utilizes Original imported CNC drive control system and software from Italy (1200W). Main beams are cut with precision (14000mm*3500mm) in one-time processing, ensuring maximum stability and no steel deformation.
All spare parts are from world-famous brands to ensure the long-term reliability and service life of the flatbed.
Equipped with the famous German WABCO braking valve to significantly shorten braking distance, enhancing safety for both trailers and drivers.
Durable mechanical widened spring suspension ensures stability. Optional air bag suspensions are available for superior shock absorption and improved fuel efficiency.
ℹ️ Product Information
The tri axle 40 ft flatbed container carrier trailer features a relatively wide wheelbase due to the extended rear axle, providing superior driving and steering stability compared to ordinary double tires.
The vehicle is finished with high-quality polyurethane paint, which offers a beautiful appearance and high durability for up to 5 years of use.
Synchronous welding methods are applied to the main beam to increase strength and durability. These 3 axle flat deck trailers are designed to transport 20ft or 40ft containers as well as bulk cargo.
Triple axle flat bed trailers are carefully engineered to specific heights and weight capacities to safely transport cargoes between shipping facilities and terminals.
📸 Visual Showcase
❓ Frequently Asked Questions
Q1: What is the maximum payload capacity of the 40ft flatbed trailer?
A: The trailer is available in different configurations with payload capacities of 40 tons, 60 tons, and up to 80 tons.
Q2: Can I use this trailer for different container sizes?
A: Yes, it is specifically designed to carry both 20ft and 40ft containers, equipped with 4, 8, or 12 sets of twist locks.
Q3: What braking system is installed on the trailer?
A: We use high-quality KEMI or German WABCO braking systems with multiple air chambers to ensure short braking distances and maximum safety.
Q4: What are the benefits of the polyurethane paint used?
A: Polyurethane paint provides a more aesthetic finish and a highly durable protective layer that can withstand harsh environments for approximately 5 years.
Q5: Which type of suspension should I choose?
A: Mechanical suspension is ideal for heavy loads and durability, while air suspension provides better shock absorption for fragile cargo and helps with fuel efficiency.
Q6: How is the main beam manufactured for durability?
A: We use high-strength steel processed by Italian CNC cutting systems and synchronous welding methods to ensure the beam is robust and resistant to deformation.
