High-Quality Cargo Tonnage Can Customized Dump Semi Trailer Manufacturer, Factories

1 / 3

High-Quality Cargo Tonnage Can Customized Dump Semi Trailer Manufacturer, Factories

Shandong Shodailer Automobile Manufacturing Co., Ltd. offers a highly efficient and versatile rear dump semi trailer that is widely utilized in sandstone plants, construction sites, and mines. This semi trailer is designed to transport and offload bulk goods such as sand, gravel, earthwork, and mining materials with ease.

It is highly applicable in various industries including construction, agriculture, recycling, and many others. The rear dump semi trailer provides a convenient and effective solution for carrying and unloading heavy materials, making it an essential equipment for any job site.

Shandong Shodailer Automobile Manufacturing Co., Ltd. ensures high-quality manufacturing and reliable performance, making their rear dump semi trailer a valuable asset for any business.

Send Inquiry

Product Description

Name	Rear dump semi trailer
Dimension	870025503550mm (side wall customized)
Payload	50ton, 80ton
Tire	11R22.5, 12R22.5, 315/80R22.5, Triangle, Double coin, Linglong.
Axles	13T/16T/20T Fuwa, BPW
King Pin	2 inch or 3.5 inch JOST Brand
Brake System	KEMI, WABCO with Four double Two single air chamber
Landing Gears	Standard 28 Ton, Fuwa, JOST
Suspension	Mechanical suspension, Air suspension
Floor	3mm, 4mm, 5mm smooth plate
Functions	Transport construction materials such as sand, clay, and plate materials etc.

The semi dump trailer capacity adopts 214 hydro cylinders, offering not only strong power but also exceptional quality to prevent overturning during operation.

The trailer rear box plate uses 4 turn-over brackets, which significantly strengthens the cargo structure.

The suspension system is multi-reinforced, featuring 10 mm thickness and a 70 mm diameter center pin to enhance overall stability.

Equipped with famous brand landing gear, ensuring a service life of more than 10 years.

Hydraulic tipper semi trailers can be customized with different tonnages to suit various cargo requirements.

Key Advantages of Tipper Semi Trailer

The cargo bottom features multiple reinforcements for maximum strength and prevents deformation over time.

Double cargo locks ensure safety; even on bumpy roads, the trailer remains securely closed.

Constructed with high-strength steel and equipped with reliable hydraulic HYVA cylinders for heavy-duty loading (40t-80t).

Available in 2, 3, 4, 5, and 6-axle models with customizable shapes like U-shape, end dump, and side tipper.

Technical Structural Features

1. Double-plate main beam provides stronger carrying capacity and resistance to damage.

2. Heavy-duty hydraulic cylinder with wider diameter for stable lifting and anti-rollover protection.

3. Lattice structure side doors with 4 units vice beam and cross balance beam for solid durability.

4. Reinforced leaf springs for superior shock absorption under heavy loads.

Frequently Asked Questions

Q1: What is the payload capacity of the rear dump semi trailer? A: The trailer supports a payload of 50 tons to 80 tons, depending on the specific model and customization.

Q2: What materials is this trailer suitable for transporting? A: It is widely used for transporting construction materials such as sand, clay, gravel, earthwork, and mining rocks.

Q3: How does the hydraulic system prevent overturning? A: It uses high-quality 214 hydro cylinders and a reinforced heavy-duty structural design with a wider diameter to ensure stable lifting.

Q4: Are the axles and tires customizable? A: Yes, we offer various axle options (13T/16T/20T from Fuwa or BPW) and multiple tire brands like Triangle, Double Coin, and Linglong.

Q5: What types of dump trailer shapes are available? A: You can choose from U-shape dump, end dump, side tipper, and container tipper designs based on your project needs.

Q6: How durable is the trailer's construction? A: The trailer is built with high-strength steel, featuring double-plate main beams and reinforced ribs to maximize payload and service life.
