China Tanzania Side Dump Semi Trailer Order Manufacturer, Supplier
Product Description
!
Technical Specifications
| Name | Side dump semi trailer |
| Dimension | 12500*2550*2700mm (customized) |
| Payload | 40ton, 60ton, 80ton |
| Tire | 11R22.5, 12R22.5, 315/80R22.5, Triangle, Double coin, Linglong. |
| Axles | 13T/16T/20T Fuwa, BPW |
| King Pin | 2 inch or 3.5 inch JOST Brand |
| Brake System | KEMI, WABCO with Four double Two single air chamber |
| Landing Gears | Standard 28 Ton, Fuwa, JOST |
| Suspension | Mechanical suspension, Air suspension |
| Floor | 3mm, 4mm, 5mm diamond steel plate |
| Side Wall | High strength T980, Height can be 60mm/80mm/100mm or customized |
| Functions | Transport stone and sand, coal, grain and corn etc |
✓
Product Overview
Side Dump Trailer for sale suitable for large workplaces, Side Tipper Trailer carrying capacity can be customized according to your need.
The side dump trailer thickness of the sidewall and bottom plate is 4 mm, which promise the cargo will not deform even the trailer carries heavy goods.
Side tipper trailer can provide more carrying space and carrying capacity. Since the side of the vehicle body can be opened outwards, it is easy to load and unload goods up and down, and the loading volume can be increased without increasing the length of the vehicle, thereby improving transportation efficiency.
?
Frequently Asked Questions
What materials can the side dump semi trailer transport?
It is specifically designed to transport heavy bulk goods such as stones, sand, coal, grain, corn, and other construction or agricultural materials.
What is the maximum payload capacity available?
We offer multiple configurations including 40-ton, 60-ton, and heavy-duty 80-ton capacities to meet different transportation requirements.
Can the dimensions of the trailer be customized?
Yes, while our standard dimension is 12500*2550*2700mm, we can customize the length, width, and height based on your specific operational needs.
What are the advantages of a side tipper compared to a rear tipper?
Side tippers provide more carrying space and improved efficiency in areas with height restrictions. Since the body opens outwards, it allows for faster unloading in narrow workplaces.
What kind of braking and suspension systems are used?
The trailers are equipped with high-quality systems like WABCO or KEMI braking systems and offer options for either mechanical or air suspension.
How does the trailer ensure durability under heavy loads?
The trailer features a 4mm thick sidewall and bottom plate made of high-strength T980 steel, ensuring the structure remains undeformed even under maximum load conditions.
